GOLD SERIES

Specifications Technical Data

Length	48.03"	Width	7.09"
Thickness	5mm	Wear Layer	20mil
Finishing	Wood Emboss	Edge Description	Micro Bevel
Sqft/Box	23.64	lb/Box	40.0
Box/Plt	55	Sqft/Plt	1300
lb/Plt	2230	Plt/FTL	19

Static Coefficient of Friction	ASTM C1028	N/A	Dry 0.69 Wet 0.56 Good
Peel Strength of Adhesive Bonds	ASTM D903	≥5.5Lbs./Inch	10.3Lbs./Inch Best
Abrasion Resistance of Organic Coatings by the Taber Abraser	ASTM D4060	N/A	Abrasion Wheel H-18 Load Applied 1000 Grams Number Of Cycles:14000 Best
Critical Radiant Flux	ASTM E648	N/A	Exceeds Class 1 Better
Resistance to Chemicals	ASTM F925	0 - No change (----) 1 - Slight change 2 - Moderate change 3 - Severe change	0 No Change Good
Heavy Metal Content Analysis	ASTM F963	N/A	Not Detected Good
Static Load Limit	ASTM F970	N/A	0.003 Inch Good
Heat Stability of Resilient Flooring by Color change	ASTM F1514	N/A	Gray Scale Rating 5 No Change Best
Light Stability of Resilient Flooring by Color change	ASTM F1515	N/A	Gray Scale Rating 5 No Change Good
Short-Term Indentation and Residual Indentation of Resilient Floor Covering	ASTM F1914 ASTM F3261	N/A	0.002 inch Surface Integrity: No puncture through wear layer / decor into rigid core. Best
Micro-Scratch Resistance (A & B)	EN 16094	N/A	MSR-B1 Best
Determination of Dimensional Stability and Curling after Exposure to Heat	ISO 23999 ASTM F3261	Length mean ≦0.25 Width mean ≦0.25%	Length mean =0.02% Width mean =0.04% Best
Determination of Locking Strength for Mechanically Assembled Panels	ISO 24334	≥2KN/m	Long Side 5.6 KN/M Short Side 3.1 KN/M Good
Laminate Floor Coverings - Determination of Geometrical Characteristics	ISO 24337	N/A	Good
Sound Transmission Class	ASTM E90-09 (2016) ASTM E413-16	N/A	STC 52 Good
Impact Sound Transmission	ASTM E492-09 ASTM E989-18	N/A	Impact Insulation Class IIC 62 Good
Determining Resistance of Synthetic Polymers to Fungi	ASTM G21	N/A	Rating 0, No Fungal Growth on Sample Best
Smoke Density (Non-Flaming)	ASTM E662	≦450	291 Best
Smoke Density (Flaming)	ASTM E662	≦450	237 Best
